Product advantages:
1. Precise control, with multiple functions such as pressure control and displacement control.
2. C-type structure, adopting the classic C-type structure design, not only provides stable support, but also increases the effective working space by optimizing the layout, which is convenient for the placement and removal of large workpieces.
3. Easy to operate, the equipment adopts a touch screen and button operation interface.
4. Safe and reliable, with fault alarm and protection functions.
Application field: PDSP-G02 ground-type C-type press has excellent performance and broad application prospects in the automotive manufacturing industry with its high strength and stability, high-precision servo control, professional design, efficient automation, safety protection and reliability. It can not only meet the high-precision requirements of automotive structural parts bushing press, but also improve production efficiency and product quality. It is one of the indispensable important equipment in the modern automotive manufacturing industry.
Series Model: PDSP-G02 |
Rated pressure | kN | 50 | 100 |
Mode Selection | Pressure mode/position mode |
Maximum speed | mm/s | 125 | 100 |
Repeatability | mm | 0.01 | |
Stroke length | mm | 500 | 500 |
Pressure accuracy | | ±0.5%F.S |
Rated Power | kW | 5.5 | 7.5 |
Supply voltage | V | Three-phase AC 380V | Three-phase AC 380V |
Features | High-strength integrated body |
