Professional Services Paris High-end OEM/ODM Ground-Type Three-Platen Four-Column Press in Factory & Suppliers-Zhitong

Product advantages:
1. Precise control, with multiple functions such as pressure control and displacement control.
2. Three-platen four-column structure, with high guiding accuracy and high press parallelism.
3. Easy to operate, the equipment uses a touch screen and button operation interface.
4. Safe and reliable, with fault alarm and protection functions.
Application field: PDSP-G03 ground-type three-platen four-column press is not only suitable for the high-precision press-fitting needs of the battery industry, but also widely used in other fields that require high-precision press-fitting and assembly. Such equipment can be used for press-fitting and assembly operations of precision parts in industries such as automobiles, electronics, and aerospace.

Series Model: PDSP-G03
Rated pressure	kN	100
Mode Selection	Pressure mode/position mode
Maximum speed	mm/s	100
Repeatability	mm	0.01
Stroke length	mm	200
Pressure accuracy	±0.5% F.S
Rated Power	kW	9.0
Supply voltage	V	Three-phase AC 380V
Features	High-strength body, high-precision guidance
